Status

Added 03/2014, updated 12/2015

Form-factor

Rugged flashlight-style handheld

CPU Speed

Texas Instruments Sitara AM37x ARM Cortex-A8/1.0 GHz

OS

Windows Embedded CE 6.0, Windows Embedded Handheld 6.5

RAM/ROM

512MB/4GB Flash ROM

Card slots

1 micro SD,; 100-pin expansion interface

Display type

Transflective sunlight-readable TFT (240 nits)

Display size/res

3.7"/480 x 640 pixel VGA

Digitizer/pens

Resistive touch/1

Keyboard/keys

Backlit 46-key alphanumeric (C model), 26-key numeric or full alphanumeric (S model)

Navigation

directional control, touch

Housing

Plastic/metal

Operating Temp

-4° to 122°F (-20° to 50°C)

Humidity

5-95% non-condensing

Sealing

IP65

Shock

Multiple 6-foot drops to concrete

Size (WxHxD)

Model C: 3.95 x 8.8 x 1.65 inces
Model S: 3.95 x 7.9 x 1.65 inches

Weight

Model C: 18.6 oz
Model S: 16.2 oz

Power

3.7V, 2,760mAH Li-Ion; optional: 3.7V, 4,400mAH Li-Ion

Interface

USB, audio

Scanning

Optional integrated or as slim pod: 1D standard or extended range laser, 1D or 2D imager

RFID

Optional LF, HF or UHF RFID modules

Camera

Optional 8mp AF camera with LED illuminator

Wireless

Bluetooth Class II, ver 2.0 + EDR, 802.11a/b/g/n; optional UMTS/HSPA+ (data only) with GPS support, optional GPS/WiFi diversity antenna
